The high angle wavy sideband is composed of base band, sideband and diaphragm. The edge guard is used to prevent the material from sliding and scattering. In order to bypass the drum, the baffle edge is designed to be corrugated; the diaphragm plate is used to support materials, in order to achieve high angle transportation, T-type TC type is used. The baffle and diaphragm are connected with the baseband by the method of secondary vulcanization, with high connection strength

產品特點(普通型大傾角波狀擋邊輸送帶)：

Product features (ordinary large angle corrugated edge retaining conveyor belt):

1、增大了輸送角度(30~90度)；

1. Increase the conveying angle (30-90 degrees);

2、占地面積小，投資少；

2. Small area and less investment;

3、輸送量大、提升高度更高；

3. Large conveying capacity and higher lifting height;

4、從水平到傾斜(或垂直)能平穩過渡；

4. Smooth transition from horizontal to inclined (or vertical);

5、適宜輸送易撒落的粉狀、粒狀、小塊狀、糊狀及液態狀物料；

5. Suitable for conveying powder, granular, small, paste and liquid materials which are easy to be scattered;

6、能耗低、結構簡單、膠帶強度高、使用壽命長。

6. Low energy consumption, simple structure, high belt strength and long service life.

3、品種

3. Variety

稱裙邊隔板帶輸送帶

Scale skirt partition belt conveyor belt

簡介：1、產品介紹（普通型大傾角波狀擋邊輸送帶）

Introduction: 1. Product introduction (ordinary large angle corrugated edge conveyor belt)

大傾角波狀擋邊帶由基帶、擋邊、橫隔板3部分組成。擋邊起防止物料測滑撒落的作用。為便于繞過滾筒，檔邊設計成波紋狀；橫隔板的作用是承托物料，為了實現大傾角輸送，采用T型TC型。檔邊和橫隔板是用二次硫化的方法與基帶連接的，具有很高的連接強度

The high angle wavy sideband is composed of base band, sideband and diaphragm. The edge guard is used to prevent the material from sliding and scattering. In order to bypass the drum, the baffle edge is designed to be corrugated; the diaphragm plate is used to support materials, in order to achieve high angle transportation, T-type TC type is used. The baffle and diaphragm are connected with the baseband by the method of secondary vulcanization, with high connection strength

產品特點（普通型大傾角波狀擋邊輸送帶）：

Product features (ordinary large angle corrugated edge retaining conveyor belt):

1、增大了輸送角度(30~90度)；

1. Increase the conveying angle (30-90 degrees);

2、占地面積小，投資少；

2. Small area and less investment;

3、輸送量大、提升高度更高；

3. Large conveying capacity and higher lifting height;

4、從水平到傾斜（或垂直）能平穩過渡；

4. Smooth transition from horizontal to inclined (or vertical);

5、適宜輸送易撒落的粉狀、粒狀、小塊狀、糊狀及液態狀物料；

5. Suitable for conveying powder, granular, small, paste and liquid materials which are easy to be scattered;

根據覆蓋膠性能不同分為普通型、耐熱型、難燃型、耐寒型、耐酸堿型、耐油型等。

According to the different properties of covering rubber, it can be divided into common type, heat-resistant type, flame-retardant type, cold resistant type, acid and alkali resistant type, oil resistant type, etc.
