We all know that the conveyor belt on the conveyor is in a ring structure, but the conveyor belt sold from the manufacturer is usually not in a ring structure. If we want to use the conveyor belt normally, we need to bond the conveyor belt. Therefore, the quality of the joint of steel wire rope conveyor belt is very important for the use of subsequent conveyor belt. A good joint of steel wire rope conveyor belt can extend the life of the conveyor belt and ensure the smooth operation during the operation. Now let's introduce the following tips for installing the connector.

1、安裝接頭的方法有很多種，常用的方法有機械接頭、冷粘接頭以及熱硫化接頭。通常來說，機械接頭是使用皮帶式的扣接頭，這樣的接頭對于安裝來說方便、快捷，但是缺點是它的效率相較于其他接頭來說比較底，而且還容易被損壞。雖然有些缺點，但是機械接頭還是很多人使用的，一般8級帶以下的輸送帶都會采用這種接頭來連接。

1. There are many ways to install joints. The common methods are mechanical joints, cold bonded joints and hot vulcanized joints. Generally speaking, the mechanical joint is a belt type buckle joint, which is convenient and fast for installation, but its disadvantage is that its efficiency is lower than other joints, and it is easy to be damaged. Although there are some disadvantages, mechanical joints are still used by many people. Generally, the conveyor belt below grade 8 belt will be connected with such joints.

2、還有一種接頭是冷粘接頭，它的原理是用冷粘粘合劑來粘接，這樣子的方法相較于上面提到的機械接頭效率會更高，但是沒有那么的經濟實惠，而且它所要求的工藝條件難度較高，對于粘合劑的要求也很高，使用的實際情況不是很穩定。相較于冷粘接頭，熱硫化接頭是目前看來實際使用情況更理想的一種方法，它同時具備了率、高穩定、長壽命、易操作等多種優點，其缺點則是操作工藝復雜度高、成本高、操作時間較長等。

2. Another kind of joint is cold adhesive joint. Its principle is to use cold adhesive to bond. Compared with the mechanical joint mentioned above, this method will be more efficient, but it is not so economical and affordable. Moreover, the process conditions it requires are more difficult, the requirements for adhesive are also very high, and the actual situation of use is not very stable. Compared with the cold bonded joint, the hot vulcanized joint is the most ideal method in actual use at present. It has many advantages such as high efficiency, high stability, long life and easy operation. Its disadvantages are high complexity of operation process, high cost and long operation time.

3、粘接鋼絲繩輸送帶并不一定只能使用一種方法，一條完整的環形輸送帶也不一定只有一個接頭，可以根據需要來采取不同的接頭方法來粘接，一般冷粘接頭和熱硫化接頭用的是階梯式結構的接頭方法。以上所說的方法是分層輸送帶的接頭的安裝方法。

3. It is not necessary to use only one method to bond the steel wire rope conveyor belt. A complete circular conveyor belt does not have only one joint. Different joint methods can be adopted to bond according to the needs. Generally, the joint method of ladder structure is used for cold bonding joint and hot vulcanization joint. The method described above is the installation method of the joint of the layered conveyor belt.

4、不同的輸送帶有不同的安裝接頭方法，而比較難安裝接頭的輸送帶是pvc和pvg整芯阻燃輸送帶。因?yàn)檫@種輸送帶的結構比較特殊，安裝的難度有點高。8級以下的安裝主要是采用機械接頭，而8級以上的輸送帶，為了保證輸送帶的使用效果，還是多使用熱硫化的接頭方式，要注意的是，這種接頭的結構都是指狀的，這樣能夠更好的連接接頭。

4. Different conveyor belts have different installation methods of joints, but the conveyor belts that are difficult to install joints are PVC and PVC whole core flame-retardant conveyor belts. Because of the special structure of the conveyor belt, the installation is a little difficult. Mechanical joints are mainly used for the installation below grade 8, while for the conveyor belt above grade 8, in order to ensure the use effect of the conveyor belt, the hot vulcanization joint mode is often used. It should be noted that the structure of this joint is finger shaped, so that the joint can be better connected.

以上就是對于鋼絲繩輸送帶接頭的簡單的介紹，要想保證輸送帶的正常運行，接頭是非常重要的一環，在連接接頭的時候千萬不能掉以輕心。

The above is a brief introduction to the joint of the steel wire rope conveyor belt. To ensure the normal operation of the conveyor belt, the joint is a very important part. When connecting the joint, you must not take it lightly.
